8-Channel Isolated Digital Input Module (ADAM-4052-BE)

by Advantech

Part #: ADAM-4052-BE

View Detailed Description


Call for Availability

The ADAM-4052 provides eight digital input channels: six fully independent isolated channels and two isolated channels with a common ground. All have 5000 V RMS isolation to prevent ground loop effects and prevent damage from power surges on the input lines.

  • Six fully independent isolated channels.
  • Two isolated channels with common ground
  • Isolation voltage: 5000 V RMS
Digital InputChannles8
Input VoltageLogic level 0: 1 VDC max. Logic level 1: 3~30 VDC
DisplayLED IndicatorsPower
GeneralWatchdog TimerSystem (1.6 second)
Connector2 x plug-in terminal block (#14~22 AWG)
Temperature (Operating)-10~70 °C (14~158 °F)
Humidity5~95 %RH
Temperature (Storage)-25~85 °C (-13~185 °F)
Isolation Protection5,000 VRMS
Communication ProtocolASCII command
Communication SpeedSerial: From 1,200 to 115.2 k
Comm. DistanceSerial: 1.2 km
Data Flow ControlYes
Power SupplyPower Requirement10~30 VDC
