1G Industrial Compact Flash, SLC 1-Channel P8 DMA (SQF-P10S1-1G-P8C)
by Advantech
•Part #: SQF-P10S1-1G-P8C
View Detailed Description
$17.00
Call for Availability
Due to supply chain inconsistencies, our team will need to verify availability before we can add this item to your cart. Click here to call.
SQF-P10 P8 is using Toshiba 32/24nm SLC NAND Flash Chips with CF Type-I interface and UDMA transfer mode provides superb performance as a boot device. In order to help protect customers’ intellectual property and maintain system stability, Advantech has designed-in their own SQFlash software package, which includes Security ID, Flash Lock, Life Monitoring and Emergency Erase features, so security and early warning functions can be more easily developed for applications.
- SQFlash software package
- Shock resistance, anti-vibration and low power consumption
- Advanced wear-leveling and block management
- Built-in EDC/ECC up to 48 random bits error per 2K bytes
- Compliant with CFA 3.0 & 4.1specification
| SQFlash | Interface | IDE / PCMCIA |
| Transfer Protocol | UDMA 2 | |
| Connector | CF Type-I | |
| Flash Type | SLC | |
| Capacity | 1 GB | |
| Operational Temperature | 0 ~ 70 °C | |
| SQFlash Utility | Support | |
| Shock | 1,500G, Peak / 0.5 ms | |
| Vibration | 20G, Peak / 80 ~ 2,000 Hz |
